Normal Grade Power Cables Fiber PP Filler Yarn , 80000D Untwisted Cable Materials

Minimum Order Quantity : 1000 kgs Price : negotiable
Packaging Details : 5kg/roll, 30kg/roll, 45kg/roll Delivery Time : 25--30 days
Payment Terms : T/T, L/C Supply Ability : 1000 tons per month
Place of Origin: Jiangxi, China Brand Name: Longtai, ANAN
Certification: REACH, ROHS, ISO 9001 Model Number: pp filler yarn

Detail Information

Advantage: Good Effect Of Cable Filling, Suitable For Large Cable Breaking Strength: 0.2-2g/d
Breaking Elongation: <20% Hot Shrinkage Rate: 4.5-6%
Specification: 9000D -- 130KD Color: White
High Light:

Power Cables PP Filler Yarn

,

Fiber PP Filler Yarn

,

80000D PP Filler Yarn

Product Description



Lower Price Power Cables Fiber PP Polypropylene Filler Yarn 80000D Untwisted

SPLIT YARN, used as the cable and wire filler. It's a good and economical substitute as cable
filler, also can apply in optical fiber cable and submarine cable in high-tech field.



Characteristics & Advantages:



Non-Toxic: It is therefore absoulutely safe for usage, without any problem of public harm.
Clean, Acidproof, Alkaliproff, Waterproof: 100% made from Polypropylene resin.
Good Toughness & Good Heat-Resistance.
Accurate specification with sufficient source supply.
Light: specific gravity: 0.915
Easy to handle with proper package. Absoultely no harm to the worker in operating. Save your cost.



1. 100% pp filler yarn or PP + Coca3 for wire and cable
2. ROHs/REACH Standard;
3. have patent
4. for wire cable filling
5. certificate: ISO 9001 by AF



Main specification:



Specification

Length/KG

(M/KG)

Elongation (%)

Pulling strength (N)

Heat shrinkage (%)

Twisted diameter (mm)

2000D 4500 15↓ 30↑ 2.5↓ 0.4
4000D 2400 15↓ 50↑ 2.5↓ 0.5
5000D 1800 15↓ 55↑ 2.5↓ 0.6
8000D 1125 15↓ 80↑ 2.5↓ 1.0
10000D 935 15↓ 90↑ 2.5↓ 1.2
12000D 750 15↓ 100↑ 2.5↓ 1.5
15000D 600 15↓ 150↑ 2.5↓ 1.8
20000D 450 15↓ 200↑ 2.5↓ 2.2
30000D 300 15↓ 300↑ 2.5↓

2.6



Normal Grade Power Cables Fiber PP Filler Yarn , 80000D Untwisted Cable Materials 0





Item Unit Spec of standard filler Spec of common filler
Linear Density D +/-10% +/-10%
Breaking strength g/D 0.6--1.4 0.2--0.6
Breaking elongation % <20 <20
Hot shrinkage rate % 4.5 6





Specification data sheet for reference:



Density 9KD 18KD 30KD 60KD 90KD 120KD 195KD 630KD 1130KD 1630KD 1935KD
g/m+/-10% 1g/m 2g/m 3.67g/m 6.67g/m 10g/m 13.3g/m 21.67g/m 70g/m 112g/m 182g/m 215g/m
Diameter 1mm 2mm 3mm 4mm 5mm 6mm 8mm 12mm 16mm 20mm 33mm





Color: Common color is white and transparent, flame resistant pp-filled yarn is light blue.



Normal Grade is suitable for large cables and is low in price. It is used for example in power cables, aerial cables, rubber cables, etc.



Common Filler Advantage:



cheap price, suitable for large cable



High Grade is suitable for all kinds of cables with a lower unit weight and reasonable price, no joint inside.



Normal Grade Power Cables Fiber PP Filler Yarn , 80000D Untwisted Cable Materials 1



PP filler material:



pp rope  Specificatioms
pp rope Item Unit pp rope standard Remark
Fineness D specification±8% 3000D-1136000D
pp rope Breaking g/d >1.5-2.5
pp rope tenacity
Tensibility % <20
shrinkage % <10 120*30min
in hot air
Appearance Natural  Color   or   White,color
obvious  stations
