Low Smorking White FR PP Filler Yarn Flame Resistance For Cable Filling Material
Low Smorking White FR PP Filler Yarn Flame Resistance For Cable Filling Material Low Smorking White FR PP Filler Yarn Flame Resistance For Cable Filling Material Low Smorking White FR PP Filler Yarn Flame Resistance For Cable Filling Material Low Smorking White FR PP Filler Yarn Flame Resistance For Cable Filling Material Low Smorking White FR PP Filler Yarn Flame Resistance For Cable Filling Material
Contact Now

Low Smorking White FR PP Filler Yarn Flame Resistance For Cable Filling Material

Minimum Order Quantity : 1000kgs Price : negotiable
Packaging Details : 25kg/woven bag, pallet Delivery Time : 25-30days
Payment Terms : L/C, T/T Supply Ability : 500T/month
Place of Origin: Jiangxi, Ganzhou Brand Name: Longtai
Certification: SGS Model Number: PP Filler Yarn

Detail Information
Color: Milky White Specification: 9KD--300KD
Twisted: 4-10 TPM Weight: 5-50kg/roll
Package: Woven Bag Breaking Strength: 0.2-1.4g/d
Hot Shrinkage Rate: <6% Breaking Elongation: <20
Tube: ID 74mm And H 440mm Or Other Material: Pp + Caco3
High Light:

White FR PP Filler Yarn

,

Low Smorking PP Filler Yarn

,

9KD Flame Retardant Material

Product Description

Newest Low Smorking White FR PP Filler Yarn Flame Resistance For Cable filling Material
Specifications:

Low Smorking Flame Retardant PP Yarn is made of 100%Polypropylene or PP+Caco3. The advantage of Filler Yarn are environmentally friendly and low smoke. Low Smorking Flame Retardant PP Yarn is very good material which can instead of glass fiber rope and asbestos rope. It is use for lots of different types of cable.

1. 100% PP filler yarn

Linear Density

12000D

18000D

28000D

33000D

48000D

60000D

70000D

90000D


(weight)g/m

1.33+0.13
-0.13


2+0.2
-0.2

3.11+0.31
-0.31

3.67+0.37
- 0.37


5.33+0.53
-0.53

6.67+0.67
-0.67

7.77+0.77
-0.77

10+1.0
-1.0


Diameter
(mm)

1.5

2

2.5

2.7

3.2

3.8

4.5

5


Breaking
Strength
(kg)
equal or more

24


36

56

66


96

120

140


180

(%)
Breaking Elongation
equal or more

10


10

10

10


10

10

10


10



2. Standard cable pp filler  yarn with mixed Caco3 :
   0.5----30MM,   4----10 TPM
   Standard pp cable filler yarn, price is not high, good effect of cable filling,
   no knot packing, can be used in kinds of cable and wire



Advantage: Cheap price, suitable for large cable.


Linear Density

D

+/-10%

0.5 --30MM
Denier:9000D---300KD


Breaking Strength

g/D

0.6--1.4




Breaking Elongation


%

20




Hot Shrinkage rate


%

6

100°C*1min.


Tube size

mm

       1  ID: 90, H:255
       2. ID: 38, H:220
       3. ID: 50, H:270
       4. ID: 75, H:440
       5. ID: 55, H: 300-400


Packing

5----50KG/ROLL




                                            PP+Caco3 Wire Cable PP Filler Specificatioms

Item

Unit

standard

Remark



pp filler  Fineness

D

specification±8%

9000D-300000D



pp filler  Breaking

g/d

>0.6g/d--1.4



tenacity



Tensibility

%

<20



shrinkage

%

<10

120*30min



in hot air



Appreance

Natural  Color   or   Milky White
