Conductive Aluminum Foil Adhesive Tape , Adhesive Aluminum Foil Tape

Contact Now

Conductive Aluminum Foil Adhesive Tape , Adhesive Aluminum Foil Tape

Minimum Order Quantity :	500kgs	Price :	$ 4.8/kg
Packaging Details :	OD 360mm,carton box	Delivery Time :	10 days after order confirmed
Payment Terms :	L/C, T/T, Western Union, D/P, D/A	Supply Ability :	500Tons/month

Place of Origin:	China	Brand Name:	Longtai
Certification:	ISO 9001, ISO14001	Model Number:	25U

Detail Information
Material:	Aluminum And Polyester	Thickness:	15um - 25um
Color:	Blue Or Silver	Property:	Insulation
ID:	2inch Or 3inch	Width:	10mm~50mm
High Light:	10mm Aluminum Foil Adhesive Tape , Conductive Aluminum Foil Adhesive Tape , 15um Aluminum Foil Tape

Product Description

Factory Wholesale Aluminum Foil Adhesive Tape Conductive Adhesive Aluminum Foil Tape

Feature
(1)  High peel strength, good initial viscosity, strong cohesion, cohesion, flame retardant performance.

(2)  Weatherability and high and low temperature performance, composite surface after the smooth and smooth characteristics.

(3) Thermally conductive, moisture, solvent resistant and UV resistant.

(4) Well use on different irrgular surface

Name	Aluminum Foil Tape	Backing Thickness	25mic	Tacking Roll ball	8.0CM
Size	50mic2inch50m	Glue thickness	25mic	Tensile Strength	75N/25MM
Material	Aluminum Foil +Acrylic glue	Adhesion to steel	10N/MM

Conductive Aluminum Foil Adhesive Tape , Adhesive Aluminum Foil Tape 0

Structure:

Aluminum Foil + Polyester Film Lamination (AL+PET)

Aluminum Foil + Polyester Film + Polyester Film Lamination (AL+PET+AL)

Color:

Original color silver, blue, red, yellow, green, etc.Variety of colors is available for indentification.

Packaging:

PAD: Max OD: 1000mm, Spool: Normal 300mm(length)*300mm(high)

Different packaging can be customized

Storage: Room temperature under dry conditions, the shelf life of 1 year

Thickness	Width	Length	OD	ID
0.01mm-0.3mm	3mm-1200mm	300m-30000m	100mm-1000mm	52mm/76mm

Technical Data:

1. AL + PET

Constructure	Total Thickness	Weight	Yield
Constructure	Total Thickness	(g/m2)	(m2/kg)
AL9 PET12	24 mic	44	22.7
AL9 PET15	27 mic	48	20.8
AL9 PET19	31 mic	54	18.5
AL9 PET23	35 mic	60	16.7
AL12 PET12	27 mic	53	18.9
AL12 PET15	30 mic	57	17.5
AL12 PET19	34 mic	62	16.1
AL12 PET23	38 mic	68	14.7
AL12 PET36	51 mic	88	11.4
AL15 PET19	37 mic	70	14.3
AL25 PET12	40 mic	88	11.4
AL25 PET23	51 mic	103	9.7
AL40 PET12	55 mic	128	7.8
AL40 PET15	58 mic	132	7.6
AL40 PET23	66 mic	144	6.9
AL40 PET36	79 mic	162	6.2
AL50 PET12	65 mic	155	6.5
AL50 PET15	68 mic	160	6.3
AL50 PET23	76 mic	171	5.8
AL50 PET36	89 mic	189	5.3

2. AL + PET + AL

Constructure	Total Thickness	Weight	Yield
Constructure	Total Thickness	(g/m2)	(m2/kg)
AL9 PET12 AL9	35 mic	70	14.3
AL9 PET15 AL9	38 mic	75	13.3
AL9 PET19 AL9	42 mic	80	12.5
AL9 PET23 AL9	46 mic	86	11.6
AL12 PET15 AL12	44 mic	91	11
AL12 PET23 AL12	52 mic	102	9.8
AL20 PET12 AL20	57 mic	130	8
AL25 PET12 AL25	67 mic	157	6

Note: Above values are the accumulative typical ones by recognized test method, but ensure you to select our products properly, please feel free to contact us for more details.
