Light Weight PP Foamed Tape 125 µm Binder in the Wrapping of the assembled insulated cable cores
Contact Person : Ariel Zhang
Phone Number : +86 13580878248
WhatsApp : +8613580878248
| Minimum Order Quantity : | 1000 kgs | Price : | 1.8-2.5/kg |
|---|---|---|---|
| Packaging Details : | Pad Coil with Carton | Delivery Time : | 7-15 days |
| Payment Terms : | L/C, T/T | Supply Ability : | 800 tons per month |
| Place of Origin: | China | Brand Name: | Longtai |
|---|---|---|---|
| Certification: | Reach Rohs ISO 9001 | Model Number: | Polyester Tape |
|
Detail Information |
|||
| Material: | Polyester | Type: | Cable Insulation Material |
|---|---|---|---|
| Application: | Power Cable, Communication Cable, Coaxial Cable, Magnetic Wires And Other Special Cables | Color: | Transparent |
| Certification: | ISO 9001 | Oem: | Support |
| Feature: | Heat Resistance | Sample: | Provided |
| High Light: | 12um Cable Wrapping Tape,15um Cable Wrapping Tape,Stranded Wires PET Mylar Tape |
||
Product Description
Polyester cable wrapping tape also called PET mylar tape or PET tape
Polyester cable wrapping tape is made of PET with high tensile and good electrical characteristics
The main function of polyester(PET) cable wrapping tape is insulation especially for cable with stranded wires
Widely used in telecommunication cable, data cable,coaxial-cable,network cable,signal cable ect
Standard polyester cable wrapping tape
Heat sealed polyester cable wrapping tape
Transparent color
Polyester (PET) Cable Wrapping Tape
| Specification | Elongation (%) | Tensile strength (kgf/m²) | Basis weight (g/m²) |
| 12μm | 35↑ | 0.18↑ | 18.25 |
| 15μm | 35↑ | 0.22↑ | 20.25 |
| 25μm | 35↑ | 0.37↑ | 33.75 |
| 38μm | 35↑ | 0.58↑ | 51.3 |
| 50μm | 35↑ | 0.75↑ | 79.65 |
| 75μm | 35↑ | 1.12↑ | 86.4 |
Heat Sealed Polyester (PET) Cable Wrapping Tape
| Specification | Composition | Elongation (%) | Tensile strength (kgf/m²) | Basis weight (g/m²) | |
|---|---|---|---|---|---|
| PET | Hot melt adhesive | ||||
| 17μm | 12μm | 5μm | 35↑ | 0.18↑ | 18.25 |
| 20μm | 15μm | 5μm | 35↑ | 0.22↑ | 20.25 |
| 30μm | 25μm | 5μm | 35↑ | 0.37↑ | 33.75 |
| 43μm | 38μm | 5μm | 35↑ | 0.58↑ | 51.3 |
| 55μm | 50μm | 5μm | 35↑ | 0.75↑ | 79.65 |
| 80μm | 75μm | 5μm | 35↑ | 1.12↑ | 86.4 |
Winding Solution:
| Type | ID (mm) |
OD (mm) |
Width (mm) |
Core |
| Pad | 52 (2“), 58 (2.3"), 76 (3“), 83 (3.25"), 102(4“), 152 (6“) | Up to 600 | ≥5 | Plastic, Paper |
| Spool | 76(3“) | 250-350 | Up to 35 | Paper |
| Jumbo | 76 (3“), 152(6") | 300-1000 | 300-1000 | Paper |
Electrical characteristics:
Temperature resistance of 180 ° c, with high mechanical strength, excellent insulation shielding property, high temperature resistance, low temperature resistance, is an ideal wrapping material, mainly used as insulation and isolation, as well as increased impedance.
Packaging and Marking:
Packed in pad or spool the polyester cable wrapping tape width can be custom made.
Common width is 5mm , the maximum outer diameter can be 800mm
Slitting minimum width of 2mm, adopt shaft packing form; conventional slitting width is 5mm, bore size is 52mm or 76mm; the winding maximum outer diameter of 800mm, carton packaging.
Storage:
Polyester Tape has a shelf life of 12 months from production date if stored in unopened original packages, under dry and clean conditions at temperatures between 10-30°C. The product will be damaged if it is stored in a moist area or if it gets in contact with water.
Why chooose us :
1. We have more than 20 years’ production experience and more than 7 years exporting experience
2. A full set of advanced facilities and a team of skilled tech workers
3. Factory direct sales with competitive price
4. Best materials selection and strict quality control
5. Considerate service, prompt delivery, each inquiry will be consulted very carefully
6. A professional and excellent working team
