ISO 9001 Polypropylene Cable Filler And Armouring Yarns 0.5 Up To 30.0Mm Diameter

Minimum Order Quantity : 1000 kgs Price : negotiable
Packaging Details : 5kg/roll, 30kg/roll, 45kg/roll Delivery Time : 25--30 days
Payment Terms : T/T, L/C Supply Ability : 1000 tons per month
Place of Origin: Jiangxi, China Brand Name: Longtai, ANAN
Certification: REACH, ROHS, ISO 9001 Model Number: pp filler yarn

Detail Information

Advantage: Good Effect Of Cable Filling, Suitable For Large Cable Breaking Strength: 0.2-2.5g/d
Breaking Elongation: <20% Hot Shrinkage Rate: 4.5-6%
Specification: 2000D -- 130KD Color: White
High Light:

Armouring Yarns Polypropylene Cable Filler

,

130KD PP Yarns

,

30.0Mm Diameter PP Yarns

Product Description



ISO 9001 Polypropylene cable filler and armouring yarns 0.5 up to 30.0 mm diameter PP Yarns

Jiangxi Longtai has a broad experience within the field of polypropylene based cable filler and armouring yarns, either colored or white of color within the standard range of 0.5 up to 30.0 mm diameter, however other diameters of PP Yarns are possible available upon request.



Our PP (polypropylene) filler and armouring yarns are being produced at the highest production and quality standards specified under ISO-9001; produced from 100% virgin PP material without recycle or CaCo3, white or colored. For armouring yarns we have diverse colors such as yellow, orange, white, green and red.


The advantage of PP cable filler yarn is as below:
Excellent flexibility,ensure the cable stablility and keep the cable round
Non-absorbent material keep the high tensile strength
Acid and alkali resistance. high insulation performance
High voltage resistance, environment friendly

ISO 9001 Polypropylene Cable Filler And Armouring Yarns 0.5 Up To 30.0Mm Diameter 0

Features:

1. 100% pp filler yarn or PP + Coca3 for wire and cable
2. ROHs/REACH Standard;
3. have patent
4. for wire cable filling
5. certificate: ISO 9001 by AF

Item Unit Spec of standard filler Spec of common filler
Linear Density D +/-10% +/-10%
Breaking strength g/D 0.6--1.4 0.2--0.6
Breaking elongation % <20 <20
Hot shrinkage rate % 4.5 6



Specification data sheet for reference:


Density 9KD 18KD 30KD 60KD 90KD 120KD 195KD 630KD 1130KD 1630KD 1935KD
g/m+/-10% 1g/m 2g/m 3.67g/m 6.67g/m 10g/m 13.3g/m 21.67g/m 70g/m 112g/m 182g/m 215g/m
Diameter 1mm 2mm 3mm 4mm 5mm 6mm 8mm 12mm 16mm 20mm 33mm



Standard Filler Advantage:

A. The best price of good quality
B. Excellent service and fast delivery
C. Effective and attractive packaging

Normal Grade is suitable for large cables and is low in price. It is used for example in power cables, aerial cables, rubber cables, etc.

Common Filler Advantage:

cheap price, suitable for large cable

High Grade is suitable for all kinds of cables with a lower unit weight and reasonable price, no joint inside.

ISO 9001 Polypropylene Cable Filler And Armouring Yarns 0.5 Up To 30.0Mm Diameter 1

PP filler material:


pp rope  Specificatioms
pp rope Item Unit pp rope standard Remark
Fineness D specification±8% 3000D-1136000D
pp rope Breaking g/d >1.5-2.5
pp rope tenacity
Tensibility % <20
shrinkage % <10 120*30min
in hot air
Appearance Natural  Color   or   White,color
obvious  stations




Our Services:

A variety of products
Enough stock
Fast delivery time
Specifications can be customized
24 hours service
Prompt reply
Small orders are accepted
Perfect after-sale service


Why chooose us  :

1. We have more than 15 years’ production experience and
more than 7 years exporting experience
2. A full set of advanced facilities and a team of skilled tech
workers
3. Factory direct sales with competitive price
4. Best materials selection and strict quality control
5. Considerate service, prompt delivery, each inquiry will be
consulted very carefully
6. A professional and excellent working team

ISO 9001 Polypropylene Cable Filler And Armouring Yarns 0.5 Up To 30.0Mm Diameter 2
ISO 9001 Polypropylene Cable Filler And Armouring Yarns 0.5 Up To 30.0Mm Diameter 3
ISO 9001 Polypropylene Cable Filler And Armouring Yarns 0.5 Up To 30.0Mm Diameter 4


We pack the pp cable filler yarn in paper tubes or spools. each tube or spool in poly bag, carton and woven bag or outer package.

Longtai provide the complete process from sample testing stage to ship out the pp cable filler yarn to your country.
Please contact us for more information on our pp cable filler yarn or you can ask our sales to send you free samples
We look forward to speaking to you.
