MV LV 10KV 35KV XLPE Compound Insulation Material for LT and HT Cables
Contact Person : Ariel Zhang
Phone Number : +86 13580878248
WhatsApp : +8613580878248
| Minimum Order Quantity : | 1 ton | Price : | US$650~950/ton |
|---|---|---|---|
| Packaging Details : | 25kg per little bag or 650-800kg per jumbo bag | Delivery Time : | 7-10 Days |
| Payment Terms : | T/T, L/C | Supply Ability : | 1000 Ton/Tons per Month |
| Place of Origin: | Xinjiang,China | Brand Name: | Longtai |
|---|---|---|---|
| Certification: | SGS,RoHS,UL | Model Number: | PVC compound |
|
Detail Information |
|||
| Features: | Anti-termite & Anti-rodent & Anti-UV | Color: | Colorful |
|---|---|---|---|
| Usage: | Cable Jacket And Insulation | Material: | Virgin Pvc Resin |
| Certificate: | SGS,RoHS,UL | Density: | 1.43g/cm³~1.55g/cm³ |
| Hardness: | 70A~90A | Test Method: | BS 7655-4.2:2000 |
| Product Name: | Special FR PVC Compound | ||
| High Light: | 1.55 g/cm3 PVC Bedding Compound,PVC Bedding Material Compound,Cablel Use PVC Bedding Material Compound |
||
Product Description
Cable Grade PVC compound professional manufacturer. Specialized in the development and sales of all kinds of cable filling Materials,Wire & Cable wrapping film and PVC compound.our company is National High-tech Enterprises verified a number of patents and Applicability of Patents.We're professional manufacture for supplying Power Cable PVC Compounds,Electric Power Cable & Power Cable PVC Compounds,UL Compounds,Automotive Wire & Cable Compounds,Elastomeric Compounds,The Special PVC Compounds,TPE Compounds,Ceranic Flame Retardant & Refractory Compounds.
| 70℃ & 90℃ PVC insulation & sheathing compound 70℃ & 90℃ |
| PVC bedding & filling compound PVC |
| PVC compound for plug PVC |
1.Technical Specifications
| Property | Unit | Testing Method | Typical Value | ||
| Insulation | Sheathing | Bedding | |||
| Density | Gm/cm² | ASTM D 792 | 1.48 | 1.5 | 1.65 |
| Hardness A | Shore A | ASTM D 2240 | 70~95 | 70~95 | 70~95 |
| Tensil Strength | N/mm² | IEC60811-1-1 | 12.5 | 12.5 | 6 |
| Elongation at break | % | IEC60811-1-1 | 150 | 150 | 125 |
| Max.Variation of Elongation after ageing for 7 days at 100 ºC | % | IEC60811-1-2 | ±25 | ±25 | / |
| Max.Variation of Tensile strength after ageing for 7 days at 100 ºC | % | IEC60811-1-2 | ±25 | ±25 | / |
| Min.Insulation resistance constant K@20 ºC | M ohm.km | ASTM , D 257 | 36.7 | / | / |
| Max. loss of mass | mg/cm2 | IEC 60811-3-2 | 1.5 | / | |
| Volume Resistivity 23℃ | ≥Ω cm | ASTM D 257 | 10¹3 | 10¹2 | / |
| Thermal stability @ 200℃ | Minutes | ASTM D 2115 | 45 | 50 | 50 |
2.Use and standard: normally for cable and wire
3.Process: extrusion
4.Appearance: cylindrical particles, plastication should be good, the color and luster is even, without obvious impurity.
5.color: Any colors, base on requirement.
Black and white, gre for Shealthing PVC compound
Red, Yellow, Blue, White and black for Insulation PVC compound
6.Packing: 25kg net weight per in a kraft bag,We could support packaging agreed on by both manufacturer and client !
20 Tons per 20GP, 26Tons per 40GP
7. Transportation and Storage:
This kind of product in the transportation should not be weathered, should be stored in a clean, cool, dry and ventilated warehouse , storage period is from the date for a year.
8.Factory Introduction:
Our factory is located in Shangyou industrial zone, Shangyou country,Ganzhou city,Jiangxi province, and setting up sales office and warehouse in Dongguan city. The new and standard factory is built on 40,000 sq. mtr with a total annual capacity of approximately 10,000 tons of various products,covers 2 flame retardant production-line, 7 cable filler yarn production-line,32 twisted machine, with full modernization of testing equipment. All of the products can be exported freely.
The company has passed the ISO 9001:2008 quality system certification. Each of these products can reach to environmental requirement by SGS company: such as ROHS, REACH-SVHC, Halogen Free. More than 30% of products are exported to Europe, America, Japan, Southeast Asia and Africa, having cooperation with many well-known listed companies at home and abroad.
We always sincerely welcome any domestic and overseas customers with great enthusiasm.
9.How To order :
1. Let me know the models, specification, quantities, colors you want to order
2. We will email you the Proforma Invoice based on your order information
3. Kindly check the PI, everything is ok, we will start production as soon as receiving payment deposit or LC, then
deliver the goods on request, original documents will be send against full payment
10,Product show:
