Twist Polypropylene Cable Filler Yarns For Increasing Tensile Strength Of Cables

Minimum Order Quantity : 1000kgs Price : 0.7-1
Packaging Details : 25kg/woven bag Delivery Time : 25-30days
Payment Terms : L/C, T/T, Western Union Supply Ability : 500T/month
Place of Origin: Jiangxi Brand Name: Longtai
Certification: SGS Model Number: PP Filler Yarn

Detail Information

Color: White Specification: 20KD--250KD
Twisted: 4-10 TPM Weight: 5-50kg/roll
Package: Woven Bag Breaking Strength: 0.2- 0.6 G/d
Hot Shrinkage Rate: <6% Breaking Elongation: <20
High Light:

Twist Polypropylene Cable Filler Yarns

,

PP Polypropylene Cable Filler Yarn

,

White Polypropylene Cable Filler Yarn

Product Description



PP filler yarn(non-twist) Dia.3mm, 3.4g/M

pp + caco3 pp cable filler yarn, 0.6-2.6g/d suitable for all kind of cable

The product should be white ,dry clean,soft and uniform thickness.

The specifications of the filling line size should comply with the provisions in the table



Item(mm) PP filler yarn(non-twist)
Specifications(mm) 30 60 90 120 160 180 270 360
Membrane width error(mm) ±3.0 ±5.0

±6.0



Thickness(mm) 0.08
Thickness of the error(mm) 0.01
After Nian corresponding diameter(mm) 2.0 2.0 4.0 4.5 5.0 5.5 6.0 7.0
The diameter tolerance(mm) ±0.3 ±0.4 ±0.6 ±0.6 ±0.6 ±0.7 ±0.7 ±0.7
Twist(mm) 3.0 3.0-3.5



Physical and mechanical properties shall meet the provisions of the table



Properties Breaking strength(flame retardant)≥N





elongation≤

Unit weight(flame retardant)g/m





Oxygen index(%)

Corresponding value
30 49(50) 15 ≤1.03 ≥28 2.0±0.3
60 63(100) 20 ≤2.02(1.70) 3.0±0.4
90 95(150) 20 ≤2.90(2.55) 4.0±0.6
120 127(200) 25 ≤3.86(3.4) 4.5±0.6
160 158(200) 25 ≤4.64(4.38) 5.0±0.6
180 191(200) 25 ≤5.42(4.96) 5.5±0.7
270 220(200) 30 ≤8.44(7.60) 6.0±0.7
360 220(200) 30 ≤11.5 7.0±0.7



PP filler yarn(twist)



Physical and mechanical properties shall meet the provisions of the table



Fill the rope specifications Diameter Quality of unit length(fiame retardant is not more than)





Twist

mm mm g/m a/200mm
Φ8 8±0.5 31.5(28) 3.0-3.5
Φ10 10±0.6 42.5(39)
Φ12 12±0.6 54(48)
Φ15 15±0.8 77(75)
Φ18 18±1.0 110(108)
Φ20 20±1.0 153(147)
Φ24 24±1.5 205(200)



Twist Polypropylene Cable Filler Yarns For Increasing Tensile Strength Of Cables 1Twist Polypropylene Cable Filler Yarns For Increasing Tensile Strength Of Cables 2Twist Polypropylene Cable Filler Yarns For Increasing Tensile Strength Of Cables 3Twist Polypropylene Cable Filler Yarns For Increasing Tensile Strength Of Cables 4Twist Polypropylene Cable Filler Yarns For Increasing Tensile Strength Of Cables 5
Twist Polypropylene Cable Filler Yarns For Increasing Tensile Strength Of Cables 6
