Rigid Flame Retardant PVC Granules For Low Voltage Telecommunication Lines RoHS UL
Rigid Flame Retardant PVC Granules For Low Voltage Telecommunication Lines RoHS UL Rigid Flame Retardant PVC Granules For Low Voltage Telecommunication Lines RoHS UL Rigid Flame Retardant PVC Granules For Low Voltage Telecommunication Lines RoHS UL Rigid Flame Retardant PVC Granules For Low Voltage Telecommunication Lines RoHS UL
Contact Now

Rigid Flame Retardant PVC Granules For Low Voltage Telecommunication Lines RoHS UL

Minimum Order Quantity : 18000 KGS Price : USD 0.9~1.2 / KG
Packaging Details : 20-25kg/pp woven bag, 1000kg/ jumbo bag, or as customized Delivery Time : 1 weeks
Payment Terms : L/C, T/T, D/A, D/P Supply Ability : 1000 TON/ Month
Place of Origin: Ganzhou, China Brand Name: Anan
Certification: SGS, ROHS, UL Model Number: UL PVC Granules

Detail Information
Color: Black And Colorful Density: 1.32-1.60g/cm³
Materiial: Raw PVC Resin And Oil Certificate: SGS, ROHS, UL
Characteristic: Hard & Rough & Wearproof Usage: Cable Sheathing & Insulation
Hardness: 80A~95A Package: 1000kgs/jumbo Bag
MOQ: 1000KGS Advantage: Stable Quality & Cheap Price
Highlight:

Rigid PVC Granules

,

Telecommunication Lines PVC Granules

,

RoHS Certified PVC Compound

Product Description





Rigid Flame Retardant PVC Granules of low voltage telecommunication lines RoHS,UL



Technical Data Sheet:





Description



Unit

DOHA

Cables Requirements
Colour - Black
Porosity - Nil
Density gm/cm3 1.50 ± 0.03*
Shore hardness A 90 ± 3
Minimum Tensile strength before ageing N/mm2 12.5
Minimum Elongation before ageing % 150

Minimum Tensile strength after ageing for 7 days at

100 ± 2 ºC

 N/mm2 12.5
Tensile strength variation % ± 25%

Minimum Elongation after ageing for 7 days at 100 ±

2 ºC

 % 150
Elongation variation % ± 25%
Maximum depth of indentation % 50
Minimum Volume Resistivity @ 23 ºC Ohm.cm 1012
Minimum Thermal Stability @ 200 ºC minutes 50
Maximum Loss of mass after ageing 7 days at 100 ºC mg/cm2 1.5




All the mechanical properties of supplied PVC like tensile strength and elongation before and after aging should meet IEC 60502-1 and BS 7655 requirements and the values indicated in the technical data as below. All the tests are conducted in accordance with IEC 60811.

Rigid Flame Retardant PVC Granules For Low Voltage Telecommunication Lines RoHS UL 0Rigid Flame Retardant PVC Granules For Low Voltage Telecommunication Lines RoHS UL 1



Rigid Flame Retardant PVC Granules For Low Voltage Telecommunication Lines RoHS UL 2Rigid Flame Retardant PVC Granules For Low Voltage Telecommunication Lines RoHS UL 3
