Fire Retardant 1.5g/cm3 PVC Compound For Cable Insulation Sheathing
Contact Person : Ariel Zhang
Phone Number : +86 13580878248
WhatsApp : +8613580878248
Minimum Order Quantity : | 1000kgs | Price : | USD 0.95-1.2/Kilogram |
---|---|---|---|
Packaging Details : | 25KG/small bag, 1000kgs/jumbo bag | Delivery Time : | 10 Days |
Payment Terms : | T/T, L/C, , Western Union | Supply Ability : | 1000 Ton/Tons per Month |
Place of Origin: | Jiangxi,China | Brand Name: | Anan |
---|---|---|---|
Certification: | Reach, Rohs, UL, TSCA | Model Number: | PVC Compounds |
Detail Information |
|||
Color: | As Customers' Request | Usage: | For Cable Insulation&Jacketing |
---|---|---|---|
Material: | Virgin Pvc Resin+oil | Certificate: | SGS,RoHS,UL, Reach |
Tensile Strength: | 12.5Mpa | Density: | 1.35g/cm³~1.55g/cm³ |
Hardness: | 75A~90A | Test Method: | BS 7655-4.2:2000 |
MOQ: | 1MT | Advantage: | Competitve Price+stable Quality |
High Light: | Shock Proof PVC Granule,85A PVC Granules,12.5Mpa PVC Compound |
Product Description
ST2 90C PVC Granules Natural Shock proof 85A Insulation Cable Tensile Strength 12.5Mpa
1.Technical Specifications
Test | Unit | Standard | |||
Test Method is as per BS 7655-4.2:2000 | |||||
Properties in the state as manufactured | |||||
Tensile Strength | Mpa | minimum | 12.5 | ||
Elongation at Break | % | minimum | 150 | ||
Properties After Aging in air oven | |||||
Ageing conditions | |||||
Temperature | ℃ | 100±2 | |||
Duration | h | 7*24 | |||
Tensile Strength | Mpa | minimum | 12.5 | ||
Variation | % | maximum | 25 | ||
Elongation at Break | % | minimum | 150 | ||
Variation | % | maximum | 25 | ||
Bending Test at Low Temperature | |||||
Test Conditions | |||||
Temperature | ℃ | -15±2 | |||
Results to obtained | No Cracks | ||||
Elongation Test at Low Temperature | |||||
Test Conditions | |||||
Temperature | ℃ | -15±2 | |||
Results to obtained | |||||
Elongation without break | minimum | 20 | |||
Impact Test at Low Temperature | |||||
Temperature | ℃ | -15±2 | |||
Requirement | No Cracks | ||||
Pressure Test at High Temperature | |||||
Test Conditions | |||||
Temperature | ℃ | 90±2 | |||
Results to obtained for Depth of Indentation | % | maximum | 50 | ||
Resistance to cracking | |||||
Temperature | ℃ | 150±2 | |||
Requirement | No Cracks | ||||
Loss of Mass | |||||
Ageing conditions | |||||
Temperature | ℃ | 100±2 | |||
Duration | h | 7*24 | |||
Value to be obtained for | |||||
Loss of Mass | mg/cm2 | maximum | 1.5 | ||
Hot Deformation Test(Only for specified radial thickness less than 0.4mm) | |||||
(As per BS 6469-99.1,clause10) | |||||
Deformation | maximum | 40 | |||
Insulation Resistance Constant | |||||
(As per BS 6469-99.2,clause8) | |||||
Temperature | 20±2 | ||||
K Value | 0.0035 |
2,Use and standard: wire and cable
3,Process: extrusion
4,Appearance: cylindrical particles, plastication should be good, the color and luster is even, without obvious impurity.
5,color: Any colors, base on requirement.
6,Packing: 25kg net weight per in a kraft bag.
7, Transportation and storage:
This kind of product in the transportation should not be weathered, should be stored in a clean, cool, dry and ventilated warehouse , storage period is from the date for a year.
We will also produce the products according with customer's requirement, For example, Flame-resisting compounds, Low temperature resisting compounds, Heat-resistant compounds, and low smoke low halogen compounds, Transparent PVC compounds etc.
8.Factory Introduction:
Our factory is located in Shangyou industrial zone, Shangyou country,Ganzhou city,Jiangxi province, and setting up sales office and warehouse in Dongguan city. The new and standard factory is built on 40,000 sq. mtr with a total annual capacity of approximately 10,000 tons of various products,covers 2 flame retardant production-line, 7 cable filler yarn production-line,32 twisted machine, with full modernization of testing equipment. All of the products can be exported freely.
The company has passed the ISO 9001:2008 quality system certification. Each of these products can reach to environmental requirement by SGS company: such as ROHS, REACH-SVHC, Halogen Free. More than 30% of products are exported to Europe, America, Japan, Southeast Asia and Africa, having cooperation with many well-known listed companies at home and abroad.
We always sincerely welcome any domestic and overseas customers with great enthusiasm.
9.How To order :
1. Let me know the models, specification, quantities, colors you want to order
2. We will email you the Proforma Invoice based on your order information
3. Kindly check the PI, everything is ok, we will start production as soon as receiving payment deposit or LC, then
deliver the goods on request, original documents will be send against full payment
