2 Ply Colored Yellow Ripcord Twist Polyester Yarn Used For UTP CAT6 Network Cable

Minimum Order Quantity : 1000KGS Price : 1.5-2.3/kg
Packaging Details : Plastic bag with tube and pallet Delivery Time : 3-4 weeks
Payment Terms : L/C, T/T Supply Ability : 800 TONS/Month
Place of Origin: China Brand Name: Jiangxi Longtai
Certification: ISO 9001, Reach,Rohs Model Number: Ripcord

Detail Information

Feature: Eco-Friendly,High Tenacity Twist: S/Z,Twist,Non-twisted
Strength: High,Standard Material: Polyester / Nylon / Aramid
Yarn Type: Filament Color: Black,raw White,yellow
Packing: Plastic Bobbin,Paper Bobbin,based On Your Request Quality: High-quality Yarn
High Light:

ROHS Twist Polyester Yarn

,

UTP Twist Polyester Yarn

,

CAT6 Network Cable Thread Yarn

Product Description





2 Ply Colored Yellow Ripcord Twist Polyester Yarn used for UTP CAT6 Network Cable



Rip cords are industrial yarns located longitudinally just under the jackets that cover conductor wires in cables. The purpose of a rip cord is to cut back the jacket to expose the wires of the cable so you don't run the risk of cutting any of the wires inside (you pull the cord, it cuts the jacket). This helps make splicing cables easier during installations.



Common Types of Rip Cords



Rip cords are made from a wide variety specialty yarns. Some of the most common yarns used are:

Nylon
Aramid (Para-aramid)
Polyester



Here are some basic product specifications for our most popular nylon, polyester, and aramid ripcord options.



NYLON RIPCORDS



Most Popular Nylon Ripcord Constructions Strength Yield Diameter Elongation
Monocord (lbs) (yds/lb) (mm)
840/1 Nylon 18 5,300 0.008 20 %
1050/1 Nylon 20 4,250 0.01 22 %
1260/1 Nylon 28 3,500 0.011 20 %
Cabled (lbs) (yds/lb) (mm)
840/1/2 Nylon 34 2,650 0.02 21 %
1260/1/4 Nylon 112 885 0.042 20 %
1680/2/3 Nylon 220 450 0.055 22 %



POLYESTER RIPCORDS



Most Popular Nylon Ripcord Constructions Strength Yield Diameter Elongation
Monocord (lbs) (yds/lb) (mm)
1000/1 Poly 20 4,400 0.01 13%
1300/1 Poly 24 3,400 0.011 13%
1500/1 Poly 30 2,800 0.0145 13%
Cabled (lbs) (yds/lb) (mm)
1000/1/2 Poly 35 2,070 0.0235 20 %
1000/1/4 Poly 70 1,035 0.0315 20 %



ARAMID RIPCORDS



Most Popular Nylon Ripcord Constructions Strength Yield Diameter Elongation
Monocord (lbs) (yds/lb) (mm)
1000/1 Aramid 50 4,400 0.01 3-4%
1500/1 Aramid 72 2,800 0.0145 3-4%
Cabled (lbs) (yds/lb) (mm)
1000/1/2 Aramid 90 2,070 0.0235 4-5%
1000/1/3 Aramid 140 1,380 0.03 4-5%
1500/1/2 Aramid 140 1,380 0.0315 4-5%
1500/1/3 Aramid 200 935 0.0355 4-5%



Product Show:



2 Ply Colored Yellow Ripcord Twist Polyester Yarn Used For UTP CAT6 Network Cable 0

2 Ply Colored Yellow Ripcord Twist Polyester Yarn Used For UTP CAT6 Network Cable 1

2 Ply Colored Yellow Ripcord Twist Polyester Yarn Used For UTP CAT6 Network Cable 2

2 Ply Colored Yellow Ripcord Twist Polyester Yarn Used For UTP CAT6 Network Cable 3



Jiangxi Longtai designs, develops, manufactures, and delivers innovative threads and yarns for wire and cable manufacturing or installation. We design wire and cable binders, ripcords of various materials, and strength members to meet or even exceed your requirements for abrasion resistance, processing speed, yield, gauge, and weight restrictions.



2 Ply Colored Yellow Ripcord Twist Polyester Yarn Used For UTP CAT6 Network Cable 4



Jiangxi Longtai is a global leader in developing and manufacturing engineered yarns and threads. We help customers who are having processing and design challenges, or material availability issues solve these problems by sharing our diverse experience, global supply chain partnerships and advanced material processing techniques.
