High Quality Flexible Glass Fiber Textile Yarn 785 Tex For Fiber Optic Cables

Minimum Order Quantity : 1000 KGS Price : 0.5-1/kg
Delivery Time : 2-3 weeks Payment Terms : L/C, T/T
Supply Ability : 3000 MT/Month
Place of Origin: China Brand Name: Longtai
Certification: Reach,Rohs Model Number: Glass Yarn

Detail Information

Application: Cable Filler Color: White
Packing: 2.5---40KG/roll Feature: Glass Yarn Armoured Fiber Yarn
High Light:

785tex glass fiber textile yarn

,

Flexible Glass Fiber Textile Yarn

,

Cables Flexible Glass Fiber Textile Yarn

Product Description



High-quality flexible glass fiber textile yarn 785tex for fiber optic cables



Glass yarn (Glass yarn with Water Blocking effect) are primarily used as peripheral strength elements in fibre optic cables. This flexible and flat glass yarn is composed from premium quality glass filaments and PU-polymeric resins to enhance the properties and increase its abrasion resistance to heavy duty processes.

Textured Glass Yarn

Textured Glass Yarn is manufactured from high performance 9 micron E-glass filaments. The glass filaments are assembled and textured by passing over high pressure air jet to produce a lofted yarn with outstanding insulation properties.



These yarns are suitable for various types of further processing, such as weaving, braiding, or knitting … etc. E-glass Textured Glass Yarn has an excellent heat resistance. It withstands 550°C. For applications where higher temperature is required we offer Textured Glass Yarn leached with 750°C or 850°C high temperature coating.



In case a requirement for temperature resistance is even higher, we produce Textured Yarn from S glass, Silica or basalt fibres. For special applications, we can also blend Glass Textured Yarn with plastic fibres.





Specification



1. Direct Yarn



Linear Density
(tex)
Length Per Kilogram
(m/kg)
Breaking Strength
(N)
Nominal Diameter
(μm)
Combustible Content
(%)
Water Content
(%)
300±5% 3333 ≥0.30 14 0.55±0.15 ≤0.10
600±5% 1667 16
1200±5% 833 16
2400±5% 416 24
4800±5% 208 24
8800±5% 113 27
9600±5% 104 28



2. PU Impregnate Yarn



Specification Unit Standard Type Water Blocking Type
Linear Density Tex 600 785 1200 2400 600 785 1200 2400
Linear Density Tolerance % ±10
Density g/cm³ 2.55±0.55
Tensile Strength - Break N ≥300 ≥330 ≥600 ≥850 ≥300 ≥330 ≥600 ≥850
Tensile Strength – LASE0.5% ≥65 ≥90 ≥140 ≥260 ≥65 ≥90 ≥140 ≥260
Tensile Strength – LASE1.0% ≥130 ≥180 ≥300 ≥550 ≥130 ≥180 ≥300 ≥550
Tensile Strength – LASE1.5% ≥210 ≥270 ≥400 ≥780 ≥210 ≥270 ≥400 ≥780
Elongation at break % ≥2.0
Tensile Modulus
(Young Modulus)
Gpa ≥75
Water Swellable Rate % N/A ≥300
Yarn Width mm 2.2 2.8 3.8 4.3 2.2 2.8 3.8 4.3
Yarn Thickness mm 0.16 0.2 0.25 0.3 0.18 0.25 0.26 0.32



High Quality Flexible Glass Fiber Textile Yarn 785 Tex For Fiber Optic Cables 0High Quality Flexible Glass Fiber Textile Yarn 785 Tex For Fiber Optic Cables 1



Packaging & Shipping



1, Direct Yarn



Yarn ID
(mm)
Yarn Height
(mm)
Yarn OD
(mm)
Yarn Weight
(kg)
Core
160 260, 265 270-275 17 Empty, without bobbin



2. PU Impregnate Yarn



Yarn ID
(mm)
Yarn Height
(mm)
Yarn OD
(mm)
Yarn Weight
(kg)
Core
94 220, 275 200-240 8-16 Paper





Application :



Glass Yarn Armoured Fiber Optic Cable Series are meant for duct applications. Dielectric strength member – Glass Yarn, gives protection to the cable against rodent attacks. Because of their dielectric nature cables can be laid along with high voltage lines inside ducts.
